產品規格
型號 | 尺寸 | 通徑 | Cv | 最低工作壓力 | 最高工作壓力 | 密封材料 | 閥體材料 | 線圈 | |
---|---|---|---|---|---|---|---|---|---|
AC | DC | ||||||||
FCFP3115 X X X | 1/2" | 15 | 4.5 | 0.01MPa | 0.6MPa | 0.6MPa | EPDM VITON |
UPVC CPVC |
FC1B |
FCFP3120 X X X | 3/4" | 20 | 9.3 | 0.01MPa | 0.6MPa | 0.6MPa | FC1B | ||
FCFP3125 X X X | 1" | 25 | 12 | 0.01MPa | 0.6MPa | 0.6MPa | FC1B | ||
FCFP3132 X X X | 1 1/4" | 32 | 24 | 0.01MPa | 0.6MPa | 0.6MPa | FE1B | ||
FCFP3140 X X X | 1 1/2" | 40 | 29 | 0.01MPa | 0.6MPa | 0.6MPa | FE1B | ||
FCFP3150 X X X | 2" | 50 | 48 | 0.01MPa | 0.6MPa | 0.6MPa | FF1B | ||
FCFP3115 X X X | F1/2" | 15 | 4.5 | 0.01MPa | 0.6MPa | 0.6MPa | FC1B | ||
FCFP3120 X X X | F3/4" | 20 | 9.3 | 0.01MPa | 0.6MPa | 0.6MPa | FC1B | ||
FCFP3125 X X X | F1 1/4" | 25 | 12 | 0.01MPa | 0.6MPa | 0.6MPa | FC1B | ||
FCFP3132 X X X | F1 1/2" | 32 | 24 | 0.01MPa | 0.6MPa | 0.6MPa | FE1B | ||
FCFP3140 X X X | F2" | 40 | 29 | 0.01MPa | 0.6MPa | 0.6MPa | FE1B | ||
FCFP3150 X X X | F2" | 50 | 48 | 0.01MPa | 0.6MPa | 0.6MPa | FF1B |
