Specifications
| Wiring method | LN01G : 2 wire, LN01G-N, LN01G-P : 3 wire |
|---|---|
| Switching logic | LN01G : N.O.式, LN01G-N, LN01G-P : Without contact, N.O. |
| Switch type | LN01G : Reed switch, LN01G-N : NPN current sinking. LN01G-P : PNP current sourcing |
| Operating voltage | LN01G : 5~240V DC/AC, LN01G-N, LN01G-P : 5~30V DC |
| Switching current | LN01G : 100mA max. LN01G-N, LN01*-P : 200mA max. |
| Switching rating | LN01G : 10W max. LN01G-N, LN01G-P : 6W max. (※1) |
| Current consumption | LN01G-N, LN01G-P : OFF : 7mA(24V)/ ON : 20mA(24V) max. |
| Voltage drop | LN01G : 3V max. LN01G-N, LN01G-P : 0.5V@200mA max. |
| Indicat | LN01G, LN01G-N : Red LED, LN01G-P : Green LED |
| Cable | LN01* : φ3.3, 2C, PVC, LN01*-N, LN01G-P : φ3.3, 3C, PVC |
| Temperature range | －10℃~＋70℃ ( No freezing ) |
| Enclosure classification | IEC 60529 IP67 |
| Protection circuit | LN01G : 1, LN01G-N, LN01G-P : 3,4 (※2) |
| Remark | ※1 : Warning: Never exceed rating ( watt = voltage × amperage ). Permanent damage to sensor will occur. ※2 : 1=None / 2=Short-circuit / 3=Power source reverse polarity / 4=Surge suppression. |
