Features

Multiplex acting, piston guide, conductive normal close.
AC voltage tolerance: ±10%. DC voltage tolerance: ±1%
Applied to sand blasting machine and high-pressure air and oil injection system
Min pressure to open: over 0.05 MPa.
Before pipelining, the pipe line must be very clean without any contaminants or impurity.
To extend the lifetime, Y-line filter should be installed in the front end of solenoid valve.
It should be installed horizontally; vertical installation is not advisable.

Specifications
